Brand

Ducati

Model

Scrambler Urban Motard 2023

Status

Available

Release Date

2022

Engine

Engine

L-Twin, Desmodromic distribution, 2 valves per cylinder, air cooled

Displacement

803 cc

Fuel Injection

Electronic fuel injection, 50 mm throttle body

Bore × Stroke

88 x 66 mm

Compression ratio

11:1

Maximum Power

73 hp (53,6 kW) @ 8.250 rpm

Maximum Torque

48,8 lb-ft (66,2 Nm) @ 5.750 rpm

Transmission

Gear Box

6 speed

Primary Drive

Straight cut gears, Ratio 1,85:1

Ratio

1=32/13 2=30/18 3=28/21 4=26/23 5=22/22 6=24/26

Starter

Electric

Exhaust

Stainless steel muffler with catalytic converter and 2 lambda probes, aluminium tail pipes

Final Drive

Chain, front spocket 15, rear sprocket 46

Clutch

Hydraulically controlled slipper and self-servo wet multiplate clutch

Chassis

Frame

Tubular steel Trellis frame

Front Tire

Pirelli Diablo Rosso III - 120/70-ZR17

Rear Tire

Pirelli Diablo Rosso III - 180/55-ZR17

Front Suspension

Upside down Kayaba 41 mm fork

Rear Suspension

Kayaba rear shock, pre-load adjustable

Steering Head Angle

-

Front Wheel

Spoked aluminium wheel 3,00" x 17"

Rear Wheel

Spoked aluminium wheel 5,50" x 17"

Wheel Travel (Front/Rear)

150 mm / 150 mm (5,9 in / 5,9 in)

Front Brake

Ø330 mm disc, radial 4-piston calliper with Bosch Cornering ABS as standard equipment

Rear Brake

Ø245 mm disc, 1-piston floating calliper with Bosch Cornering ABS as standard equipment

CO2 Emission

120 g/km

Fuel Tank Capacity

13,5 l - 3,57 gallon (US)

Fuel Consumption

5,2 l/100 km

Light

LED

Dry Weight

180 kg (397 lb)

Kerb Weight

196 kg (432 lb)

Seat Height

805 mm (31,7 in)

trail

94 mm (3,7 in)

Wheelbase

1.436 mm (56.5 in)

No of seats

Dual seat

Equipment and warranty

Standard equipment

Steel tank with interchangeable aluminium side panels, headlight with DRL by LED light-guide and interchangeable aluminium cover, LED rear light with diffusion-light, LED turn indicator, LCD instruments with gear and fuel level indications and interchangeable aluminium cover, under-seat storage compartment with USB socket, ABS cornering, machine-finished aluminium belt covers, black engine with brushed fins

Urban Motard equipment

low variable section aluminum handlebar, custom flat seat, high front mudguard, 17" spoked wheels, Pirelli Diablo Rosso III tires, side number plates, custom graphics on tank and side panels

Warranty

24 months unlimited mileage

Maintenance service intervals

12,000 km (7,500 mi) / 12 months
